VERITY 1601 ELS Detector
The VERITY® 1601 ELS Detector is an evaporative light scattering detector (ELSD). An ELSD is not dependent on UV absorbance and can detect compounds or impurities even if they do not contain chromophores, making it an ideal complementary detector to a UV-based purification system. With the use of Conditional Logic Fraction Collection in TRILUTION® LC and GLIDER Software, the VERITY 1601 ELSD can ensure pure fractions by detecting and separating impurities that are not seen by other detection methods.
VERITY 1601 ELSD expands your capabilities and secures your purification
• Detect any analytes with and without chromophore groups that are less volatile than the eluent
• Compatible with LC gradient solvent system
• Compatible with most LC solvents whatever their absorption characteristics
• Provide a very stable baseline that improves the fraction collection triggering
• Low-temperature evaporation allows detection of semi-volatile or thermally labile compounds
• The nebulization chamber has been specially designed to work with highly concentrated eluents frequent in preparative separations by HPLC or Centrifugal Partition Chromatography (CPC)
Specifications
| VERITY 1601 ELS Detector | ||
| Front Panel Control | Front panel control or computer control via Serial port and GLIDER Software | |
| Nebulizer | LC semi-preparative to preparative | |
| Temperature Range | Ambient to 100°C | |
| Typical Sensitivity | 100 ng | |
| Gas Supply | Nitrogen or Air (gas must be oil-free, dry, and filtered) Pressure: 2–4.5 bar (29–67 psi) Typical Operating Pressure: 2 bars (less than 3L/min) | |
| Data Rate | 10 Hz | |
| Safety and Compliance | The detector has been certified to safety standards specified for Canada, Europe, and the United States. Refer to the instrument rear panel label and the Declaration of Conformity document for the current standards to which the instrument has been tested. | |
| Environmental Conditions | Altitude up to 2000m Ambient Temperature 5°C–40°C Max humidity of 80% for temps under 31°C, with linear decrease down to 50% at 40°C Voltage fluctuations up to ± 10% of nominal voltage Transitory overvoltage of class II Pollution degree 2 | |
| Dimensions (W x H x D) | 250 mm (10 in.) x 330 mm (13 in.) x 550 mm (21 in.) | |
| Output | 0 – 1 Volt | |
| Power Requirements | 100V to 240V (50Hz/60Hz) | |
| Weight | 15 kg (33 lbs.) | |
